As a reliable sandblasting pot supplier, Taisheng Machinery offers affordable pressure pot sand blaster and shot blasting pots for sale.Sand blasting pot is used for cleaning, corrosion control, and surface preparation. This shot blasting pot is user friendly and inexpensive to maintain and operate.
The TS-500-1 Industrial Sandblasting Pot is engineered to handle challenging surface preparation tasks across a wide range of industries. Whether removing rust and old coatings or preparing steel surfaces for protective treatment, this equipment delivers consistent sandblasting performance even in demanding operating conditions.
The TS-500-1 industrial sandblaster is designed with a heavy-duty pressure vessel and accurate abrasive flow control. The system helps improve cleaning efficiency, reduce abrasive waste, and achieve the surface profile required for high-performance coating systems. It is an ideal solution for shipyards, steel fabrication plants, bridge maintenance contractors, and industrial maintenance teams.
High Cleaning Efficiency: The direct-pressure blasting system delivers abrasive media at high velocity. It effectively removes rust, scale, old coatings, welding slag, and various contaminants from the surfaces of steel and metal components.
Portable and Flexible Operation: Designed for easy transportation and deployment, the TS-500-1 can be used in fabrication workshops, construction sites, shipyards, bridge maintenance projects, and other outdoor industrial environments.
Wide Abrasive Compatibility: The machine supports a variety of blasting media, including steel shot, steel grit, garnet, aluminum oxide, glass beads, ceramic beads, copper slag, and other commonly used abrasives.
Easy Operation and Maintenance: The simplified control system allows operators to adjust blasting parameters efficiently. The equipment is designed with minimal wear components, helping reduce maintenance requirements and downtime.
Remote Control System: A handheld pneumatic control switch enables operators to start and stop blasting during operation, improving convenience and operational safety.
Certified Pressure Vessel Construction: The pressure vessel is manufactured and tested in accordance with applicable pressure equipment standards and is supplied with the corresponding pressure vessel certification documentation.
Extended Blasting Time: The optimized abrasive storage capacity allows approximately 45 minutes of continuous blasting per full media load, depending on nozzle size, operating pressure, and abrasive type.
Removal of scale, burrs, and welding slag from heat-treated parts, welded components, and castings (achieving Sa3 cleanliness standards);
Removal of micro-burrs and surface residues from machined parts;
Surface pretreatment prior to coating or plating to create an active surface and enhance coating/plating adhesion;
Suitable for applications such as denim sandblasting, sandblasting of steel structures and containers; rust and oxide layer removal for shipbuilding and repair, bridges, mining machinery, oil pipelines, metallurgy, boilers, machine tools, railways, machinery manufacturing, port construction, and hydraulic engineering projects; as well as surface texturing of stone.
| Model | TS-500-1 sand blasting pot |
| Tank Size (Diameter * Height) | Φ500mm * H1250mm |
| Tank Volume | 0.2m³ |
| Continuous Blasting Time | Approx. 45mins |
| Weight (approximately) | 190kg |
| Working Pressure | 0.4~0.7MPa |
| Nozzle | Boron Carbide; diameter 5/16’’ (8mm) |
| Blasting Hose | Diameter 1’’ (40mm), length 30’ (9m) |
| Control Method | Pneumatic Control |
| Air Compressor Requirement | 22kw, 0.7-1.2Mpa (air consumption 3.6m³/min) |
The TS-500-1 Industrial Sandblasting Pot uses a direct-pressure blasting system to deliver abrasive media at high velocity for surface cleaning and preparation. Compared with suction-feed systems, direct-pressure blasting provides a more consistent abrasive flow and higher cleaning efficiency for large-scale industrial applications.
Media Loading: The pressure vessel is filled with the selected abrasive media through the top loading port and sealed before operation.
System Pressurization: Compressed air from an external air compressor pressurizes the vessel, typically operating within a working pressure range of 0.4–0.7 MPa.
Abrasive Flow Control: The abrasive metering valve is used to regulate the flow of abrasive entering the compressed air stream. It allows operators to adjust the blasting intensity based on surface conditions and project requirements.
Surface Cleaning Process: The air-abrasive mixture travels through the blast hose and exits the boron carbide nozzle at high speed, removing rust, mill scale, old coatings, and other surface contaminants from the workpiece.
Operator Safety Control: A pneumatic remote-control system allows operators to start and stop blasting during operation, improving control and workplace safety.
Steel Shot & Steel Grit
For rust removal, mill scale cleaning, and structural steel preparation.
Glass Beads & Ceramic Beads
For stainless steel, aluminum, and decorative finishing.
Garnet & Aluminum Oxide
For coating preparation and abrasive blast cleaning.
Copper Slag & Coal Slag
For large-scale outdoor blasting projects.
Application: Casting Cleaning and Surface Preparation
Workpiece: Metal Castings
Objectives:
Remove burnt-on sand and casting residues
Clean heat-treatment scale and oxidation
Prepare surfaces for machining and finishing
Solution: The TS-500-1 Industrial Sandblasting Pot was integrated into the foundry's post-casting cleaning process, providing efficient abrasive blasting for large cast components and improving production throughput.
Application: Rust Removal and Coating Preparation
Workpiece: Structural Steel Components
Objectives:
Remove rust and surface contamination
Prepare steel for industrial coatings
Support routine fabrication and maintenance work
Solution: The TS-500-1 was used for abrasive blasting of fabricated steel structures prior to painting and protective coating application, helping ensure consistent surface preparation across multiple projects.
Based on field applications and customer operating experience, the TS-500-1 performs best when paired with an air compressor capable of supplying sufficient airflow and stable working pressure for the selected blasting nozzle and application requirements.
For structural steel cleaning and coating preparation, garnet abrasive and steel grit are commonly used and can help achieve Sa2.5 to Sa3 surface preparation standards under appropriate operating conditions.
For stainless steel, aluminum, and decorative metal finishing applications, glass beads and ceramic beads are commonly selected where a smoother surface finish and controlled surface treatment are required.
Proper nozzle selection, abrasive quality, media flow adjustment, and operating air pressure are key factors influencing blasting efficiency, abrasive consumption, and final surface profile quality.
A sandblasting pot is used to propel abrasive media at high speed using compressed air for surface preparation. It is commonly used for rust removal, paint stripping, mill scale removal, weld cleaning, and creating an anchor profile before coating or painting steel surfaces.
Pressure sandblasting pots are widely used in steel fabrication plants, shipyards, bridge maintenance projects, oil and gas facilities, storage tank refurbishment, construction equipment repair, pipeline maintenance, and heavy machinery manufacturing.
The TS-500-1 can work with various abrasive materials, including steel grit, steel shot, garnet, aluminum oxide, glass beads, ceramic beads, copper slag, and coal slag. The best abrasive depends on the cleaning requirement and desired surface finish.
The recommended air compressor is 22kW or larger with an operating pressure range of 0.7 MPa to 1.2 MPa and an air consumption capacity of approximately 3.6 m³/min for stable blasting performance.
Yes. The pressure blasting system provides a powerful abrasive impact that effectively removes heavy corrosion, mill scale, old paint, epoxy coatings, and surface contaminants from steel structures and equipment.
The TS-500-1 can help achieve Sa2.5 to Sa3 surface preparation standards depending on abrasive selection, operating pressure, nozzle size, and blasting conditions.
Yes. The TS-500-1 is commonly used for shipbuilding, vessel maintenance, steel plate cleaning, hull section preparation, and marine coating projects.
